The Acegear AGNVR128P4KSAT16 NVR is capable to record in full digital IP cameras up to 12MP in resolution. The system can be remote access using mobile app available for Android and Apple iOS devices, Acegear also offers a free video management software available for Windows and MacOS. The NVR has (16) SATA Bay with 12TB capacity so it will provide plenty of storage for you and it is capable to support Array RAID 0,1,5,6,10, 50, 60. Also support 2 miniSAS interfaces to connect extra Storage
| IP Video Input | 128-CH |
|---|---|
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Incoming bandwidth | 512Mbps |
| Outgoing bandwidth | 512Mbps |
| Remote connection | 128 |
| Recording resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| HDMI/VGA output | VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz HDMI1/HDMI2: 4K (3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
| Synchronous Playback | 16-ch |
| Live View Display | VGA: 1/4/6/8/9/16/25/36 HDMI1, HDMI2: 1/4/6/8/9/16/25/36/64 |
| Live view/Playback resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 3 x 12MP@25, 4 x 4K@30, 16 x 1080P@30, 32 x 960P@25, 36 x 720P@30, 64 x D1 |
| Network protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS |
| SATA | 16 SATA interface, up to 16TB for each HDD Array RAID 0, 1, 5, 6, 10, 50,60, 2 MiniSAS port, 1 eSATA interface |
| VCA | Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Vehicle Control, Temperature Detection(Fire Detection, Smoking Detection, Temperature Measurement, Smoke and Fire Detection), Ultra Motion Detection(UMD), Video Metadata, Traffic Monitoring |
| Network interface | 4 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces |
| USB interface | Front panel: 2 x USB2.0, Rear panel: 2 x USB3.0 |
| Power supply | 100~240 VAC |
| Consumption (without HDD) | ≤ 65 W |
| Working temperature | -10°C ~ + 55°C (+14°F ~ +131°F) |
| Working humidity | 10% to 90% |
| Dimensions (WxDxH) | 533mm × 482mm × 131.0mm (21.0" × 19.0" × 5.1") |
| Weight (without HDD) | ≤ 12.5 Kg (27.56 lb) |
