AtlasIED M1000 / 8″ dual cone sound masking speaker with 70v transformer and enclosure (4-Watt)
8″ DUAL CONE SOUND MASKING SPEAKER WITH 4-WATT 70V TRANSFORMER AND ENCLOSURE – BLACK
The M1000 sound masking speaker assembly is designed to accurately reproduce the required spectrum of masking signal into the plenum space. The innovative 734 cubic inch square enclosure ensures ample low frequency response. A specially designed 8″ dual cone speaker is included in the package. A high efficiency 70.7V internal transformer is coupled to an external tap selector switch for easy system tuning.
- Pre-Assembled Unit Includes 8" dia. Loudspeaker, Transformer, Enclosure, Baffle and Mounting Hardware
- Labor-Saving Hardware Package – Complete with New Snap Hanger Assembly, Allows Quick and Easy Installation
- Innovative Input Panel Includes Combination Knock-Out and Strain Relief Connector to Accommodate Flexible or Rigid Conduit
- Design Enables Upward, Downward, or Horizontal Orientation
- 734 cu in Enclosure for Extended Low Frequency Response
- Available in Black or White Epoxy Finishes to Blend with a Variety of Open Ceiling Plans
- Suitable for Use Above Suspended Ceiling Systems or Open Ceiling Spaces Approved for Use in Air Handling (Plenum Ceilings)
- Safety Listed to UL 1480 & UL 2043
Specs
| LOUDSPEAKER | 8" Dual Cone |
|---|---|
| SENSITIVITY | 97dB Peak, 94dB Average |
| FREQUENCY RESPONSE | 100Hz - 10kHz |
| SAFETY LISTED | UL1480, UL2043 |
| 70.7V POWER TAPS | 25, .5, 1, 2 and 4 |
| WIDTH | 11 9/16* |
| CERTIFIED TO SAFETY LISTING | UL1480 & UL2043 |
Additional information
| Color | Black, White |
|---|
