The Acegear AGNVR1616P4KSAT4 NVR is capable to record in full digital IP cameras up to 12MP in resolution. The system can be remote access using mobile app available for Android and Apple iOS devices, Acegear also offers a free video management software available for Windows and MacOS.The NVR has (4) SATA Bay with 10TB capacity so it will provide plenty of storage for you.
| IP Video Input | 16-CH |
|---|---|
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Incoming bandwidth | 320Mbps |
| Outgoing bandwidth | 320Mbps |
| Remote connection | 128 |
| Recording resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| HDMI/VGA output | VGA: 1920x1080p/60Hz, 1920x1080p/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz HDMI: 4K (3840x2160)/60Hz, 4K (3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
| Synchronous Playback | 16-ch |
| Decoding Format | H.265/H.264 |
| Live view/Playback resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 1 x 12MP@30, 2 x 4K@30, 5 x 4MP@30, 10 x 1080P@30, 16 x 720P@30 |
| Network protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS |
| SATA | 4 SATA interface, up to 10TB for each HDD, RAID 1,5 |
| Network interface | 1 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces |
| USB interface | Front panel: 1 x USB2.0,Rear panel: 1 x USB3.0 |
| Interface | 16 RJ-45 10M/100M self-adaptive Ethernet Interface |
| Max Power | Max 30W for single port, Max 150W in total |
| Supported Standard | IEEE 802.3af/at |
| Power supply | 100~240 VAC |
| Consumption (without HDD) | ≤ 20 W |
| Working temperature | -10°C ~ + 55°C (+14°F ~ +131°F) |
| Working humidity | 10% to 90% |
| Dimensions (WxDxH) | 400mm × 363mm × 74mm (15.7" × 14.3"× 2.9") |
| Warranty | 12 mo. with proof of purchase *exclusion apply (see warranty terms for details). |
| Weight (without HDD) | ≤4Kg (8.82lb) |
